CEMTECH PHARMA MACHINERY

De-foiling is one of the small but needful machines. It is ideal for recovering the tablets, capsule from the rejected & unsealed strips without any damage and such recovered Tablets/Capsules can be replaced on strip packing machine.

De-foiling is self contained, portable machine. The machine is fitted with a series of SS groove pressure roller, which are driven machine by spur gears. That holds the strip and gradual increase in width of the roller Tablet/ Capsule are pushed out of the pocket, the slitters & foil guides are easily and quickly adjustable according to the strip to be feed. A SS Chute is provided to collect the tablets/ capsule, which are separated from the rejected foil strip. The design is such that the tablets/ capsule and de-foiled strip are collected separately. A rotary reversible switch is provided to rotted the machine in reverse direction to clear the jamming of strip. The machine is fully guarded for operator’s safety.

Innovative Features :-

• GMP & cGMP design
• Super tight finish
• Bio safe Toxicology Tested
• Calibrated & Certified as per International Standards.
• Available in S.S 316 and S.S. 304 Quality
• Available in sizes ranging from 45mm to 90 mm.
• Import Substitute Designs

SALIENT FEATURES :-

• This unit is ideal for recovery of tablets/capsules from rejected foils.
• The foils are fed in the machine where the tablets, sitters,suitable for strip width of      45 to 90mm, and is supplied with stainless steel tablet collecting tray etc. all the shall       driven by 0.25hp, 3phase motor.

NOTE : Technical details, specification & designs are subject to change without any prior notice.
